4-plex apartment plan J0917-13-4

This fourplex plan offers a unique layout. With the units configured on a single floor, in a square pattern, this plan has entrances on multiple sides. 2 bedroom units to the front enter from a common porch while the rear units have 3 bedrooms with their main entry from the sides of the building. This fourplex layout provides flexibility for corner lots and when different style units are desired in one building. See plan, J0917-13-4B for a version with all 2 bedrooms units and plan J0917-13-4C for all 3 bedroom units.

2 and 3 bedroom units
Living area: 3894 sq. ft.
Other: 326 sq. ft.
Total: 4220 sq. ft.

Living area/unit: 1055/892 sq. ft.

Width: 64'-0"
Depth: 66'-0"

Modify this plan

Floor plan

Exterior view

Rear elevation
