Duplex plan J09053d

This is a narrow plan that can be used in different ways. For example, place it on a narrow lot or put multiple buildings on a lot to maximize the number of units. Perfect for lots that are somewhat narrow but have plenty of depth. However, due to the narrow width, they can be lined-up to increase the use of your property. See alternate version: J09053db
J09053d Rendering Mid
3 bedroom / 2 bath
Living area = 2116 sq. ft.
Other = 92 sq. ft.
Total = 2208 sq. ft.

Living area per unit: 1058 sq. ft.

Width: 24'-0"    Depth: 92'-0"
Choose Plan Option:
What's included?

5 Sets - $795.00
PDF File - $945.00
5 sets + PDF File - $1090.00
CAD Files - $1220.00
Study set-PDF - $350.00
Study set-Shipped - $395.00

Add Material list - $145.00

*Click here for information about PDF delivery times.
Floor plan
J09053d Ad Copy

Exterior view
J09053d Rendering
